DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
Auth Diagnostics
This table contains the diagnostic information regarding the operation of the Authenticator associated with each port. An entry
appears in this table for each port that supports the Authenticator function. To view the Authenticator Diagnostics, click
Monitoring > Port Access Control > Auth Diagnostics.
Figure 11- 25. Authenticator Diagnostics window
The user may select the desired time interval to update the statistics, between 1s and 60s, where “s” stands for seconds. The
default value is one second.
The following fields can be viewed:
Parameter Description
Port
The identification number assigned to the Port by the System in which the Port
resides.
EntersConnecting
Counts the number of times that the state machine transitions to the CONNECTING
state from any other state.
EapLogOffsConnecting
Counts the number of times that the state machine transitions from CONNECTING to
DISCONNECTED as a result of receiving an EAPOL-Logoff message.
EntersAuthenticating
Counts the number of times that the state machine transitions from CONNECTING to
AUTHENTICATING, as a result of an EAP-Response/Identity message being received
from the Supplicant.
SuccessAuthenticating
Counts the number of times that the state machine transitions from
AUTHENTICATING to AUTHENTICATED, as a result of the Backend Authentication
state machine indicating successful authentication of the Supplicant (authSuccess =
TRUE).
196
