D-Link DES-3052P User Manual

DES-3028 DES-3028P DES-3052 DES-3052P Layer 2 Fast Ethernet Managed Switch
LEDs
The following table lists the LEDs located on models of the DES-30xx Switches along with their corresponding description:
Location LED Indicative Color Status Description
Solid Light Power On
Power
Green
Light off Power Off
Solid Light Console on
Blinking
POST is in progress/ POST
is failure.
Per Device
Console
Green
Light off Console off
Link/Act/ Speed
Green Solid Light Link/Act/Speed Mode
“Mode Select
Button”
PoE
Green Solid Light PoE Mode
Solid Green
When there is a secure
100Mbps Fast Ethernet
connection (or link) at any of
the ports.
Blinking Green
When there is reception or
transmission (i.e. Activity—
Act) of data occurring at a
Fast Ethernet connected
port.
Solid Amber
When there is a secure
10Mbps Ethernet connection
(or link) at any of the ports.
Blinking Amber
When there is reception or
transmission (i.e. Activity—
Act) of data occurring at an
Ethernet connected port.
Link/Act/Speed
Green/Amber
Light off No link
Solid Green
Powered device is
connected.
Blinking
Port has detected a error
condition
LED Per
10/100 Mbps
Port
PoE
Green
Light off
Powered Device may receive
power from an AC power
source or no 802.3af PD is
found
Solid Green
When there is a secure
1000Mbps connection (or
link) at any of the ports.
Blinking Green
When there is reception or
transmission (i.e. Activity--
Act) of data occurring at a
1000Mbps connected port.
Solid Amber
When there is a secure
10/100Mbps Fast Ethernet
connection (or link) at any of
the ports.
Blinking Amber
When there is reception or
transmission (i.e. Activity—
Act) of data occurring at a
Fast Ethernet connected
port.
LED Per GE
Port
Link/Act/Speed
mode for
1000BASE-T ports
Green/Amber
Light off No link
4
