IGNITION DEVICES LOCATION
14-2
IGNITION SYSTEM
START SWITCH
RESISTOR
AUTO BY STARTER 5W 6.7
WINKER REALY, ASS’Y
REGULATOR RECTIFIER
CDI UNIT
STARTER REALY, ASS’Y
IG COIL
ACG. CORD COUPLER
A.C.GENERATOR
HIGH TENSION CORD
SPARK PLUG CAP ASS’Y
BATTERY ASS’Y
COMB. & LOCK SW
WIRE HARNESS
BLUE / YELLOW
PULSE GENERATOR
AC GENERATOR
MAIN SWITCH
SIDE STAND
SWITCH
IGNITION COIL
SPARK PLUG
BLACK / YELLOW
BLACK / WHITE
BLACK / RED
GREEN
CDI UNIT
