16-1
16. LIGHTS/METER/SWITCHES
TROUBLESHOOTING
Fuel meter indicator malfunctioning
● Coupler separated.
● Harness disconnected.
● Float operation malfuction.
● Fuel unit damaged.
● Meter damaged.
Fuel meter needle unstable
● Coupler loose.
● Fuel unit damaged.
● Meter damaged.
Headlight hi-lo not operating
● Bulb malfunction.
● Dimmer switch damaged.
Oil indicator light not operating
(when there is oil).
● Burned out fuse.
● Battery insufficiently charged.
● Main swtich damaged.
● Meter damaged.
● Oil level switch damaged.
● Loose connector.
● Harness disconnection.
Oil indicator does not turn off (when oil is out)
● Oil level switch damaged.
● Green/red wire joined.
SERVICE INFORMATION
GENERAL SAFETY
● Refer to tester owner’s manuals when performing continuity inspections.
● Refer to wiring diagram (chapter 17) for switch continuity.
● After inspecting and/or performing maintenance work make sure the wires and cables are properly placed and
connected.
16
SERVICE INFORMATION
16-1
TROUBLESHOOTING
16-1
FUEL UNIT
16-2
OIL LEVEL SWITCH
16-3
MAIN SWITCH
16-3
HANDLE SWITCH INSPECTION
16-4
FRONT STOP SWITCH INSPECTION
16-4
BULBS REPLACEMENT
16-5
METER REPLACEMENT
16-7
HORN INSPECTION
16-7
