10. FRONT WHEEL/FRONT FORK/STEERING
SERVICE INFORMATION
GENERAL SAFETY
● Keep oil or brake fluid off the brake disk and pad because the contaminated brake disk and pad reduces the braking
performance. If contaminated, replace the pad with a new one, and clean the disk.
● Use special tire levers and rim protectors to remove or assemble tires to protect the rim from being damaged.
● This section describes how to remove and maintain front wheels, front fork and steering system. For information on the
front brake system, refer to section 10.
● Place a jack underneath the engine to support the 2-wheeled vehicle.
SPECIFICATIONS
TORQUE VALUES
STEERING STEM LOCK NUT 7.0㎏·m
BRAKE DISK BOLT 3.9㎏f·m
FRONT AXLE NUT 6.0㎏f·m
10
SERVICE INFORMATION
10-1
TROUBLESHOOTING
10-2
STEERING HANDLE
10-3
FRONT WHEEL
10-5
FRONT AXLE DEFLECTION - 0.2mm
FRONT WHEEL RIM RUNOUT
- 2.0mm
- 2.0mm
FRONT FORK TUBE DEFLECTION - 0.2mm
FRONT FORK OIL LEVEL 58㎤ -
FORK SPRING FREE LENGTH 278.6mm -
RADICAL
AXIAL
ITEM STANDARD VALUE SERVICE LIMIT
TUBELESS TIRE
10-9
FRONT FORK
10-14
STEERING STEM
10-20
