● Connect the oil pump and then the carburetor quickly
with the both ends of the tube pressed to avoid the air
from entering.
•Make sure that the tubes are arranged correctly.
● Start the engine.
•Do not start the engine in the poorly-ventilated area.
● Open the oil pump control level fully and idle for
2minutes to bleed the air remained in the oil pass tube
with the oil drained from the oil pump.
•Do not increase the engine RPM more than required.
● Connect the oil control cable.
•Adjust the oil pump if the adjustment nut of the oil
comtrol lever is loose.
ENGINE OIL LEVEL INSPECTION
● Check the engine oil level if the pilot lamp blinks when
the main switch is turned on.
LOW OIL WARNING LIGHT BLINKING LEVEL : 0.3
4-6
LUBRICATION SYSTEM
