Parameter
Number
696 Unit: –
Data type: uint16 Access type: Read/Write
7.9.3.2 Input Terminal 33 (Menu Index 9.5.2)
P 9.5.2.1 T33 Mode
Select the working mode of terminal 33.
Default value: 1 [Voltage Mode] Parameter type: Selection
Parameter
Number
619 Unit: –
Data type: enum Access type: Read/Write
The following are the selections for the parameter.
Selection number Selection name
0 Current Mode
1 Voltage Mode
P 9.5.2.2 T33 High Voltage
Enter the voltage (V) that corresponds to the high reference value, as set in P 9.5.2.6 T33 High Ref./Feedb. Value.
Default value: 10.00 Parameter type: Range (0.00–10.00)
Parameter
Number
611 Unit: V
Data type: uint16 Access type: Read/Write
P 9.5.2.3 T33 Low Voltage
Enter the voltage (V) that corresponds to the low reference value (set in P 9.5.2.7 T33 Low Ref./Feedb.Value). The value must be set at
>1 V in order to activate the live zero timeout function in P 9.5.6.2 Live Zero Timeout Function.
Default value: 0.07 Parameter type: Range (0.00–10.00)
Parameter
Number
610 Unit: V
Data type: uint16 Access type: Read/Write
P 9.5.2.4 T33 High Current
Enter the current (mA) that corresponds to the high reference value (set in P 9.5.2.6 T33 High Ref./Feedb. Value).
Default value: 20.00 Parameter type: Range (0.00–20.00)
Parameter
Number
613 Unit: mA
250 | Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254
Application Guide | iC2-Micro Frequency Converters
