Danfoss PVED-CLS User Manual

© Danfoss | August 2018 AQ00000211 | 47
ENGINEERING TOMORROW
Min.
Max.
Generation of 5V sensor
supply voltage (Deutsch
connector pin 11)
P3248 U8 -
Sensor Supply Test. Disable/enable the internal 5V supply on the PVED-
CLS’ pin 11.
Valid Values: 0 (Enable); 1 (Disable)
Note: Should be kept at Enable (P3248 set to 0) all time
OEM 0 1 0
Table 17
7.7 STEERING DEVICE AND PROGRAM CHANGES
Different steering devices with different programs can be used together with the PVED-CLS. The PVED-CLS will lock
a steering device, when a vehicle speed threshold of P3250 is exceeded (i.e. the PVED-CLS will ignore any steering
device change messages of lower priority, if the vehicle is traveling faster than the value in P3250). If any steering
device change messages of a higher priority than current steering device are sent, the PVED-CLS will change to that
steering device.
The priority order, for steering devices is as follows:
1. Steering wheel (STW)
2. Auxiliary steering device (AUX)
3. Auto-guidance
Below the threshold, specified by P3250, it is allowed to switch between any steering device programs, no matter the
priority. Above this threshold, steering device program cannot be switched to the one with lower priority, only a steering
device with a higher priority is allowed.
The complete PVED-CLS Steering mode selection state machine is shown in chapter 3.2. Similar to the steering device
lock, the PVED-CLS will lock a steering program (AUX or STW), when a vehicle speed threshold of P3251 is exceeded
(i.e. the PVED-CLS will ignore any steering program change messages, if the vehicle is traveling faster than the value in
P3251).
The state machines for Steering wheel, AUX and Auto-guidance steering device are shown in chapter 3.3, 3.4 and 3.5.
Name
Address
Data type
Unit
Description of parameter
User
Range
Danfoss
default
value
Safety critical parameters ‘S’
Min.
Max.
Max vehicle speed for
engaging auto-guidance
or AUX steering device
P3250 U8 km/h Max vehicle speed at which a lower priority steering device can be engaged OEM 0 100 15 S
Max vehicle speed for
steering program
changes
P3251 U8 km/h
Max vehicle speed at which a steering program for the selected device can
be changed
OEM 0 100 15 S
Table 18
7.8 VEHICLE SPEED SETUP
When driving in auto-guidance mode at a low speed, the spool movement will be disabled, for safety reasons, when the
vehicle speed goes below the threshold specified P3252. The resolution is 1
x10m/h = 10 meter pr. hour.
Important
This parameter is valid for all programs (i.e. AUX, Auto-guidance and Fast-steering).
