How to Program
" Parameters: Digital In/Out
" 5-0* Digital I/O Mode
5-00 Digital I/O Mode
Option:
*
PNP [0]
NPN [1]
Function:
The digital inputs and programmed digital
outputs are pre-programmable for operation
either in P NP or NPN systems.
PNP systems are pulled down to GND. Action
is on positive going pulses (↑).
NPN systems are pulled up to + 24 V (i nternal in the
drive). Action is on negative going pulse (↓).
It is not possible to set the parameter while
the motor is running.
5-01 Termin al 27 Mode
Option:
*
Input [0]
Output [1]
Function:
Selects terminal 27 as either a digital input or
output. Default setting is the Input function. You
cannot set this pa rameter while the motor is running.
5-02 Termin al 29 Mode
Option:
*
Input [0]
Output [1]
Function:
Selects terminal 29 as either a digital input or
output. Default setting is the Input function. You
cannot set the parameter while the motor is running.
" 5-1* Digital Inputs
Parameters for configuring the input functions
for the input terminals.
The digital inputs are used for selecting various
functions in the adjustable frequency drive. All
digital inputs can be set to the following functions:
No operation [0]
Reset [1]
Coast inverse [2]
Coastandresetinv. [3]
Quick stop inverse [4]
DC brake inverse [5]
Stop inverse [6]
Start [8]
Latched start [9]
Reverse [10]
Start reverse [11]
Enable start forward [12]
Enable start reverse [13]
Jog [14]
Preset ref bit 0 [16]
Preset ref bit 1 [17]
Preset ref bit 2 [18]
Freeze reference [19]
Freeze output [20]
Speed up [21]
Slow [22]
Set-up select bit 0 [23]
Set-up select bit 1 [24]
Catch up [28]
Slow-down [29]
Pulse input [32]
Ramp bit 0 [34]
Ramp bit 1 [35]
Mains failure inverse [36]
DigiPot increase [55]
DigiPot decrease [56]
DigiPot clear [57]
Reset Counter A [62]
Reset Counter B [65]
Functions dedicated to only one digital input are
stated in the belonging parameter.
You can program all digital inputs to these functions:
• No operation [0]: The adjustable
frequency drive does not react on signals
transmitted to the terminal.
• Reset [1]: Resets the adjustable
frequency drive a fter a TRIP/ALARM. Not
all alarms can be reset.
• Coast inverse [2] (Default Digital input
27): Coasting stop, inverted input (NC). The
adjustable frequency drive leaves the motor i
n
free mode. Logic ’0’ => coasting stop.
• Coastandresetinv. [3]:Resetand
coasting stop Inverted input (NC). The
adjustable frequency drive leaves the motor
in free mode and resets the drive. Logic
’0’=>coastingstopandreset
• Quick stop inverse [4]: Inverted input
(NC). Generates a stop in accordance with
*
default setting ()display text []value for use in communication via serial communication port
