Danfoss VLT AutomationDrive FC 302 Design Guide

FC 300 Design Guide
How to Read this Design Guide
" Abbreviations
Alternating current AC
American wire gauge AWG
Ampere/AMP A
Automatic Motor Ada ptation AMA
Current limit I
LIM
Degrees Celsius °C
Direct current DC
Drive Dependent D-TYPE
Electronic Thermistor Relay ETR
Adjustable Frequenc y Drive AFD
Gram g
Hertz Hz
Horsepower HP
Kilohertz kHz
Kilowatt KW
Local Control Panel LCP
Meter m
Milliampere mA
Millisecond ms
Minute min
Motion Control Tool MCT
Motor Type Dependent M-TYPE
Nanofarad nF
Newton meter Nm
Nominal motor current I
M,N
Nominal motor frequency f
M,N
Nominal motor power P
M,N
Nominal motor voltage U
M,N
Parameter par.
Rated Inverter Output Current I
INV
Revolutions per minute RPM
Second s
Torque limit T
LIM
Volt V
" Definitions
Drive:
D
-TYPE
Size a nd type of the co nnected drive (dependencies).
I
VLT,MAX
The maximum output current.
I
VLT,N
The rated output current supplied by the adjustable frequency drive.
U
VLT MAX
The maximum output voltage.
8
MG.33.B3.22 - VLT is a registered Danfoss trademark
