B-2 Printer Specifications
Operating Specifications
The CR500 printer operates under the following specifications.
Operating Environment
Use the following environment guidelines when operating the printer.
Recording method Dye sublimation retransfer
Feed format Automatic feed
Recording density 300 dpi
Reproduction
gradations
256 levels each yellow (Y), magenta (M), and cyan (C);
two for black (K)
Printing time 29 seconds (single-sided, excluding data transfer time)
Interface Ethernet (100Base-Tx or 10Base-T)
Power supply (2) 100–120VAC or 220–240VAC (±10%)
Current dissipation 3.5A for 100V system and 1.6A for 200V system
Weight 47 lbs (21.3 kg)
Sound level Less than 70dB(A) according to DIN45635, part 19
(EN27779)
Operating temperature 63°–83°F (17°–28°C)
Operating humidity 35%–60%, non-condensing
