Table 37. EX300 hardware components (continued)
Component Description
● 4x 16GB RDIMM, 2667MT/s, Dual Rank, x4 Data Width.
● Dual 750W Platinum power supply (hot swappable).
● Each node has 4 x 10 GbE networking.
EX300 configurations
Describes the EX300 ECS appliance configurations.
The front view of an EX300 rack with the minimum node configuration and an EX300 rack with the maximum node configuration
is shown in the following diagram. The rear view requires a brace wherever there is empty space above or below an EX300
server.
Figure 72. EX300 minimum and maximum configurations
The EX300 appliance is available in the following configurations within a Dell EMC rack or a customer-provided rack.
Table 38. EX300 configurations
Nodes Disks in each node Disk Size RAW Storage capacity
5 (minimum configuration) 12
● 1 TB
● 2 TB
● 60 TB
● 120 TB
EX300 Platform 95
