Delta ASDA-B2-F Series User Manual

Wiring ASDA-B2-F
3-4 September, 2015
3
3.1.3 Wiring Method
There are two types of wiring method, single-phase and three-phase. In the diagram below,
Power On is contact a, Power Off and ALRM_RY are contact b. MC is the coil of magnetic
contactor and self-remaining power and is the contact of main power circuit.
 Wiring Method of Single-phase Supply (suitable for 1.5 kW and models below 1.5 kW)
Servo Drive
L 1C
L 2C
R
S
T
Noise Filter
Motor
MC
SUP
ALRM_RY
Power
on
Power
off
MC
RS
U
V
W
MCCB
MC
 Wiring Method of Three-phase Power Supply (suitable for all series)
Servo Drive
L1C
L2C
R
S
T
Noise Filter
Motor
MC
SUP
ALRM_RY
Power
on
Power
off
MC
TS
U
V
W
MCCB
MC
R
