Delta ASDA-B2-F Series User Manual

Wiring ASDA-B2-F
3-12 September, 2015
3
3.2.2 400 W ~ 750 W models (with built-in regenerative resistor but no
fan)
Power
1-phase/3-phase
200 ~ 230 V, 400 W ~ 750 W
L1 C
L2 C
Rectifier
Circuit
U
V
W
CN2
GATE
DRIVE
CN1
Digital Intput
Digital Output
A & B Output
Serial
Communication
RS-232
Display
MODE SHIFT
SETCHARGE
Encoder
Servo
Motor
M
Protection
Circuit
+3.3 V
Phase Loss
Detection
Regeneration
Circuit
Control Power
±15 V
+5 V
+24 V
C
S
T
D
R
P
Connect to external
regenerative resistor
Servo Drive
CN6
CN3
CN4Battery
DMCNET
Data Processing Unit
IPM Module
