Installation and Operation Manual for RPI M6A M8A M10A inverters V1.0 2016-02-03
13 Technical data
13. Technical data
Input (DC) RPI M6A RPI M8A RPI M10A
Maximum recommended PV power
1)
7500 W
P
10000 W
P
12500 W
P
Maximum power 6600 W 8800 W 11000 W
Input voltage range 200 ... 1000 V
DC
Maximum input voltage 1000 V
DC
Nominal voltage 600 V
DC
Startup voltage >250 V
DC
Startup power 40 W
MPP operating voltage range 200 ... 1000 V
DC
MPP operating voltage range with full power
Symmetrical load 315 ... 800 V
DC
415 ... 800 V
DC
415 ... 800 V
DC
Asymmetrical load (60/40%) 425 ... 800 V
DC
565 ... 800 V
DC
415 ... 800 V
DC
Maximum input current; total (DC1 / DC2) 20 A (10 A / 10 A) 20 A (10 A / 10 A) 25 A (15 A / 10 A)
Maximum short circuit current in case of a fail-
ure
13 A / 13 A 13 A / 13 A 19.5 A / 13 A
Number of MPP trackers Parallel inputs: 1 MPP tracker; Separate inputs: 2 MPP trackers
Maximum asymmetry 60/40%
Number of DC inputs; total (DC1 / DC2) 2 (1 / 1) 2 (1 / 1) 3 (2 / 1)
Galvanic isolation No
Overvoltage category
2)
II
Output (AC) RPI M6A RPI M8A RPI M10A
Maximum apparent power
3)
6300 VA 8400 VA 10500 VA
Nominal apparent power 6000 VA
4)
8000 VA 10000 VA
Voltage range
5)
230 ± 20 % / 400 V
AC
± 20%; 3 phase + PE or 3 phase + N + PE
Nominal current 8.7 A 11.6 A 14.5 A
Maximum current 9.7 A 13 A 16 A
Inrush current 31 A / 100 µs
Nominal frequency 50 / 60 Hz
Frequency range
5)
50 ± 5 Hz / 60 ± 5 Hz
Power factor adjustable 0.8 cap ... 0.8 ind
Total harmonic distortion <3%
DC current injection <0.5% rated current
Night-time loss <2 W
Overvoltage category
2)
III
