• The sub remote control unit is equipped with frequently used buttons,
so it can be used for simple remote control unit operations.
• The sub remote control unit can also be used for multi-zone, so you
can use it to control the AVR-4810 from other rooms.
• The operations listed below can be performed with the sub remote
control unit.
•
Switching the input source
•
Adjusting the volume
•
TUNER and iPod operations
•
NET/USB direct play
•
GUI menu and ZONE2 on-screen display operations
•
Zone power on/off
• It is not possible to operate devices other than the amplifier.
In ZONE4 mode, only the [ZONE OFF], [ZONE ON] and [INPUT
SOURCE SELECT] buttons can be operated.
Device operated TUNER NET/USB iPod
Zone selection M Z2 Z3 Z4 M Z2 Z3 Z4 M Z2 Z3 Z4
ZONE SELECT Zone operation mode selection
ZONE OFF
Power turned off (
b
1)
ZONE ON
Power turned on (
b
1)
INPUT SOURCE SELECT
Input source selection (
b
2)
QUICK SELECT Quick select function
CHANNEL + / – Preset channel selection – Preset channel selection –
SHIFT
Preset channel memory
block selection
–
Preset channel memory block
selection
–
VOLUME + / –
Adjustment of volume (
b
1)
–
Adjustment of volume (
b
1)
–
Adjustment of volume (
b
1)
–
MUTE
Muting (
b
1)
–
Muting (
b
1)
–
Muting (
b
1)
–
MENU Selected zone menu – Selected zone menu – Selected zone menu –
MEMORY
Preset memory
registration
–
Preset memory
registration
– –
u i o p
– Cursor – Cursor –
ENTER – Enter – Enter –
SEARCH RDS search –
Page forward screen /
Character search
–
Page forward screen /
Browse/Remote mode
switching (press and hold)
–
RETURN – Return – Return –
8 9,
TUNING d f
Tuning – Track search Track search –
2
– Stop Stop –
1
/
3
– Play/pause Play/pause –
REPEAT – 1-track/All-track repeat play 1-track/All-track repeat play –
RANDOM – 1-track random play 1-track/album shuffle play –
USB
b
3
ALL MUSIC *
(Music server only)
b
4
FAVORITES *
b
5
b1: Affects the currently selected zone.
b2: In ZONE4, only input sources to which NET/USB and digital input have been assigned can be selected.
b3: The input source switches to “NET/USB” and the files on the USB memory device are played.
b4: The input source switches to “NET/USB” and the files in “All Music” on the music server are played.
b5: The input source switches to “NET/USB” and the files in “Favorites” are played.
*: Whether “All Music” or “Favorites” is selected depends on the “Direct Play” setting (vpage 62).
Functions of Buttons by Component
DIRECT PLAY button
• Playback is possible in the mode selected at GUI menu “Direct Play”.
FAVORITES: Playback starts from the first track registered in the favorites.
ALL MUSIC: Playback starts from the first track registered in the “All Music” folder.
• When [USB] is pressed, playback starts from the first track on the USB memory device.
NOTE
When the music server is stopped or restarted, it may no longer be possible to play tracks stored in the favorites.
