Denon AVR-4810 User Manual


Getting Started Connections Settings Playback Remote ControlMulti-zone Information Troubleshooting SpecificationsConnections
ENGLISH
Speaker Connections
The AVR-4810 can be connected to a maximum of three subwoofers.
The same signal is output from each subwoofer terminal.
w q
w q
w q w q
*/
w q
(R)
(L) (R)
*/ */
(L)
C A B
Subwoofer
(1st unit)
Center
speaker
Front
speakers
Surround
speakers
Subwoofer
with built-in
amplifier
For the
A B C
speaker terminals, the output channels are different depending on the “Amp Assign” setting. Set
“Amp Assign” to suit the speaker system being used and connect the speakers referring to the following chart.
(2nd unit) (3rd unit)
A
: S.BACK/F.HEIGHT/F.WIDE and F.HEIGHT/
F.WIDE speaker terminals
Use when connecting surround back speakers, front height speakers
or front wide spekars.
Speaker connections
w q w q
(L) (R)
w q w q
(L) (R)
Surround back speakers,
Front height speakers
or Front wide speakers
Front height speakers or
Front wide speakers
Relationship between “Amp Assign” settings and channels
output by each speaker terminal
“Amp Assign”
setting
(vpage 38 ~ 40)
Channels output by each speaker
terminal
Config.
Extra
Channel
S.BACK/
F.HEIGHT/
F.WIDE
F.HEIGHT/
F.WIDE
11.1ch
(
b
)
SB/FH/FW S.BACK F.HEIGHT
9.1ch SB/FW S.BACK F.WIDE
SB/FH S.BACK F.HEIGHT
FH/FW F.HEIGHT F.WIDE
7.1ch SB S.BACK –
FH F.HEIGHT –
FW F.WIDE –
5.1ch – – –
b : Use the PRE OUT terminal for the front wide channel output.
n
n

Denon AVR-4810 Specifications

General

Impedance	8 Ω
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.05 %
Equalizer	Yes
Product color	Black
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
HDMI ports quantity	6
Connectivity technology	Wired & Wireless
Headphone connectivity	3.5 mm
Digital audio optical out	1

Weight and Dimensions

Weight	19100 g
