Getting Started Connections Settings Playback Remote ControlMulti-zone Information Troubleshooting SpecificationsPlayback
ENGLISH
Playing Components
4
Set the main remote control unit to the “NET/USB”
mode (vpage 99 “Operating the Main Remote
Control Unit”).
When no control dock for iPod is connected, this operation is also
possible in the “iPod” mode.
b
5
Press [SEARCH] and hold it down for a 2 seconds or
more to select the display mode.
There are two modes for display the contents recorded on the
iPod.
Browse mode
:
This is the mode for displaying the iPod information on the GUI
screen to operate the iPod. In this mode, you cannot perform
operations directly on the iPod itself.
z With the AVR-4810’s display, only English letters and numbers
and certain symbols can be displayed. Any characters that
cannot be displayed are replaced with “. (period)”.
Remote mode
:
This is the mode for performing operations directly on the iPod
itself while watching the screen displayed on the iPod. In this
mode, the GUI screen is not displayed.
z “Remote iPod” is displayed on the AVR-4810’s display.
The Remote mode is not supported on 5th generation iPods or
iPod nanos.
Display mode
Browse mode Remote mode
Playable
files
Audio file
S S
Picture file
A A
Movie file
A A
z
Active
buttons
Main remote
control unit
(AVR-4810)
S S
iPod
®
A S
z : Only the sound is played.
b
b
6
Use ui to select the item, then press ENTER or p to
select the le to be played.
7
Press ENTER or p.
Playback starts.
Playing an iPod
®
Connected Directly to
the AVR-4810’s USB Port
Music stored on an iPod can be played on the AVR-4810 when the
AVR-4810 and iPod are connected by USB cable.
The AVR-4810 supports iPod (5th generation and later), iPod nano,
iPod classic, and iPod touch audio (it is not compatible with iPod
shuffle). However, some functions may be limited on certain
models.
The operation may not work properly if the iPod’s software is old. Be
sure to use the latest version of iPod software.
With iPods, non-copyrighted material and material for which
duplication and playback is authorized by law can be duplicated and
played by individuals for their personal enjoyment. Infringement of
copyrights is prohibited by law.
Note that DENON will accept no responsibility whatsoever for any
problems arising with the data on an iPod when using the AVR-4810
in conjunction with the iPod.
•
•
•
•
•
Listening to music on an iPod
®
1
Connect the iPod
®
to the AVR-4810’s USB port using
the USB cable included with the iPod (vpage 23
“USB Port”).
2
Turn the AVR-4810 power on.
(vpage 27 “Turning the Power On“)
3
Press [SOURCE SELECT] to display the GUI Source
Select menu, then select “ ” (vpage 30).
– GUI screen –
DENON’s iPod
Playlistes
Artists
Albums
Songs
Podcasts
Genres
Composers
[1/9]
SEARCH
Search
When the iPod is connected directly to the USB port, menus under
“Music” are displayed.
If the screens above are not displayed, the iPod may not be
properly connected. Try connecting again.
When no control dock for iPod is connected, this can also be
selected by pressing [iPod].
b
b
b
ENTER <STATUS>
uio p
ENTER
[SEARCH]
uio p
[SOURCE
SELECT]
[iPod]
[ NET/USB]
Button located on both the main unit
and the remote control unit BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control unit [BUTTON]
Symbols used to indicate buttons in this manual
ENTER
uio p
[CHANNEL]
[SOURCE
SELECT]
[1 ~ 8]
[MEMO]
[TUNER]
[A ~ G]
[MODE]
[TUd]
[TU f]
[BAND]
[ TUNER]
When no control dock for iPod is connected, this operation is also
possible in the “iPod” mode.
b
(MAIN mode)
(MAIN mode)
(MAIN mode)
[SHIFT]
[TUNER]
Sub remote control unit
(MAIN mode)

Denon AVR-4810 Specifications

General

Impedance	8 Ω
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Total Harmonic Distortion (THD)	0.05 %
Equalizer	Yes
Product color	Black
S-Video inputs quantity	7
Component video (YPbPr/YCbCr) in	3
HDMI ports quantity	6
Connectivity technology	Wired & Wireless
Headphone connectivity	3.5 mm
Digital audio optical out	1

Weight and Dimensions

Weight	19100 g
