Enclosure Overview
High speed CPU
Intel® Core™ i7 is the most powerful processor of the
Intel® Core™ processor family.
High speed interfaces
USB 3.0 (nearly 10 times faster than USB 2.0) and
GLAN interfaces provide highest bandwidth for
data-transfer from and to the S-BOX.
Removable High speed SSD
With 180 MB/s write rate to the Solid State Disk, there
is enough capability not only for transient recording,
but also for e.g. external high-speed video cameras.
Flash option
For even better performance and maximum safety and
convenience, we recommend separating the operating
system from the measurement data.
With the S-BOX-FLASH120 option, the operating
system is stored on an internal flash disk with 120 GB,
while the measurement data is stored on the
exchangeable SSD.
This allows for a quick exchange of the SSD where
your valuable data is stored on.
This feature also allows to continue storing on a new
media immediately.
Illustration 69: SIRIUS-R8 front-side
4.6.1 Specifications R8
Physical Specifications Technical Specifications
Power Supply 12-36V
DC
Processor Intel® Core™ i7 processor
Power Consumption Typ. 25 W, (max. 55W) CPU clock frequency 4x2 GHz
Physical Dimensions 447x309x147 [mm] RAM 4 GB
Humidity (@60°C) 95% RH non-condensing Flash S-BOX-FLASH120 option
USB Front: 4x USB 3.0 SSD
240GB (960GB as option,
others on request)
Ethernet GLAN, WLAN Chipset Intel QM57
Operating Temperature 0 to 50°C
Optional GPS 10Hz, 20Hz, 100Hz, RTK
Storage Temperature -40 to 85°C
Humidity 95% RH non condensing @ 60°C
Shock & Vibration
VIBRATION SWEEP SINUS (EN 60068-2-6:2008)
VIBRATION RANDOM (EN 60721-3-2: 1997 - Class 2M2)
SHOCK (EN 60068-2-27:2009)
Doc-Version: 1.4.2 www.dewesoft.com Page 37/166
