SIRIUS®
4.7 SIRIUS-R8D
The SIRIUS-R8D is a rugged chassis which provides 8 slots for SIRIUS® measurement modules and has an integrated
powerful PC: with an Intel® Core™ i7 processor and a fast SSD drive.
The SIRIUS-R8D has the highest possible data through-put, since each measurement module has a dedicated USB2 line
to the CPU (no USB-hub).
Illustration 75: SIRIUS-R8D (left: front-side, right: rear-side)
High speed CPU
Intel® Core™ i7 is the most powerful processor of the
Intel® Core™ processor family.
High speed interfaces
USB 3.0 (nearly 10 times faster than USB 2.0) and
GLAN interfaces provide highest bandwidth for
data-transfer from and to the S-BOX.
Removable High speed SSD
With 180 MB/s write rate to the Solid State Disk, there
is enough capability not only for transient recording,
but also for e.g. external high-speed video cameras.
Flash option
For even better performance and maximum
safety and convenience, we recommend
separating the operating system from the
measurement data.
With the S-BOX-FLASH120 option, the
operating system is stored on an internal
flash disk with 120 GB, while the
measurement data is stored on the
exchangeable SSD.
This allows for a quick exchange of the SSD
where your valuable data is stored on.
This feature also allows to continue storing
on a new media immediately.
4.7.1 Specifications R8D
Physical Specifications Technical Specifications
Power Supply 12-36V
DC
Processor Intel® Core™ i7 processor
Power Consumption Typ. 35 W, (max. 65W) CPU clock frequency 4 x 2 GHz
Physical Dimensions 447x309x165 [mm] RAM 4 GB
Humidity (@60°C) 95% RH non-condensing Flash S-BOX-FLASH120 option
USB
Front: 3xUSB3, 1xUSB2
Rear: 2x USB 2.0
SSD
240GB (960GB as option,
others on request)
Ethernet GLAN, WLAN Chipset Intel QM57
Operating Temperature 0 to 50°C
Optional GPS 10Hz, 20Hz, 100Hz, RTK
Storage Temperature -40 to 85°C
Humidity 95% RH non condensing @ 60°C
Shock & Vibration
VIBRATION SWEEP SINUS (EN 60068-2-6:2008)
VIBRATION RANDOM (EN 60721-3-2: 1997 - Class 2M2)
SHOCK (EN 60068-2-27:2009)
Page 40/166 www.dewesoft.com Doc-Version: 1.4.2
