SIRIUS®
5.6 General Specifications
Misc
Power Supply 6-36V
DC
Operating Temperature -10 to 50°C (40°C for fanless series
1
)
Storage Temperature -40 to 85°C
Humidity 5% to 95% RH non condensing @ 60°C
Shock & Vibration
Sweep sinus (EN 60068-2-6:2008)
Random (EN 60721-3-2: 1997 - Class 2M2)
Shock (EN 60068-2-27:2009)
EMC EN 61326-1, EN 61000-3-2, EN61000-3-3
Counter
Timebase 102.4MHz
Time base accuracy Typical: 5 ppm, Max: 20 ppm
Max. Bandwidth 10MHz
Input Filter 500 ns, 1µs, 2µs, 4µs, 5µs and 7.5µs
Acquisition rate
Time base accuracy Typical: 5 ppm, Max: 20 ppm
Synchronisation
Delay between slices 50 nsec
USB: Max. Sync-cable length 100 m (Master/Slave), 200 m (Irig)
EtherCAT®: Max. cable length 75m
Table 8: SIRIUS® Modules: General Specifications
1 50°C with airflow of 3m/sec
Page 56/166 www.dewesoft.com Doc-Version: 1.4.2
