3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_16.03_EN_U
The PC keyboard also allows to enter a numeric or alphanumeric string (max.32 characters) and then press a key to execute
the corresponding quick function.
For example, if the function 122 (Input text 1 configuration) is combined to the F4 key (see << F.KEYS >> step,
TECH.MAN.REF.), through PC keyboard it’s possible to enter a text and the press F4 to quickly modify the input text 1.
NOTE: through the remote keyboard, it’s not possible to carry out the functions made by pressing the keys at length.
4.7 REMOTE CONTROL
Depending on the model of indicator, it is possible to remotely control the instrument through one of the following types of
remote controls: 19-key infrared (ir),18-key infrared (ir) or 6-key radio (rd).
The type of remote control to be used must be selected in the Setup environment, in the << inF.rEd >> step
(TECH.MAN.REF.).
NOTE: The infrared remote controls are for indoor use only.
4.7.1 “19-KEY” INFRARED REMOTE CONTROL
With this type of remote control, the functioning of the keys will be as described in the following table.
FUNCTION OF THE KEYS
Entry of digits or characters
Tare/zero function or increase of a digit while entering a
value
Decrease of a digit while entering a value
Scrolls the digits to the right while entering a value
Confirms the entered value or enters the displayed step
