13.3 INPUT-OUTPUT AXLE WEIGHING
In this functioning mode it is possible to get the weight of each axle with calculation of their total weight, first in input and after
in output, and therefore determine the weight difference between the 2 total weighs.
The indicator links each input weigh to the lowest available ID (from 1 to 999); consequently, if an output weigh is executed
correctly, the relative ID code will be made available for the following input weigh.
To enable this mode, one has to set the step F.ModE >> totAL >> In.out step on “ENABLE” in the setup
(TECH.MAN.REF.).
Then it is possible to select how to recall the input weigh to execute the output weigh, with ID code or with License Plate of
the truck weighed in input. This selection is done in the SETUP through the step F.ModE >> totAL >> WEi.MEM.
It’s possible to have the ID code of the input weigh to be always consequential, therefore also if an ID lower than the last
one stored is available, the ID code will follow the ID of the last stored input weigh.
To enable this function one has to set the F.ModE >> totAL >> Pro.LSt step in the set-up on “ENABLE”.
13.3.1 MANUAL AXLE WEIGHING
13.3.1.1 CONFIGURATION
- Set parameter SETUP F.ModE >> totAL >> AXLE W on “MANUAL”.
- If before was setted the DYNAMIC axles weighing, the indicator ask to set the filter of this weighing mode, press
FN/ENTER to confirm.
13.3.1.2 INPUT WEIGHING PROCEDURE
- Select, if requested, the customer / material / vehicle to be linked to the input weigh.
- Drive and stop the first axle of the vehicle on the scale then press F6 key to start the input weigh cycle and store the
first axle weight.
- The indicator waits for stability and displays the following messages:
3590E
LED display LCD display
CPWE

READING WEIGHT
XXXXXX
ENTRY WEIGH
ENTRY WEIGH

WEiGh
READING WEIGHT
SET FILTER ?
