Dini Argeo 3590ET User Manual

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_16.03_EN_U
54
alternatively to
CPWE
alternatively to
[In which: XXXXXX is the acquired overall weight value
YYYYYY UM is the acquired overall weight value with unit of measure]
- At this point, it returns in the status of waiting for the input or output weighing cycle start.
13.3.3 AUTOMATIC DYNAMIC AXLE WEIGHING
13.3.3.1 CONFIGURATION
- Set parameter in the SETUP: F.ModE >> totAL >> AXLE W on “DYNAMIC”.
- If before was setted the STATIC axles weighing, the indicator ask to set the filter of this weighing mode, press
FN/ENTER to confirm.
- For a correct functioning one should correctly set the weighing parameters in the F.Mode >> total >> StA.CFG
menu of the Set-up environment or by a direct function 605, linked to a key. (See the TECHNICAL MANUAL):
1.”Min.Wei” (Minimum weigh of the axle);
2.”n.SMPLS” (Average weight samples);
3.“tiME W” (Interval between cycles);
4.”Skip B.” (Beginning axles to skip);
5.“Skip E.” (Ending axles to skip);
6.”Err.En” (Axle acquisition error enable);
7. “SPEEd” (Speed Limit in Km/h);
8.”Tim.Out” (Axle acquisition time out).
9. “PL.Widt” (Platform width);
13.3.3.2 INPUT WEIGHING PROCEDURE
- Select, if requested, the customer / material / vehicle to be linked to the input weigh.
- Press the F6 key in order to start the input weigh cycle.
- The instrument waits for the first axle and displays:
3590E
LED display LCD display

AXLES: 2
TOT: YYYYYY UM o
tot.out
AXLES: 2
TOT: YYYYYY UM o
XXXXXX
AXLES: 2Y
TOT: YYYYY UM o
ENTRY WEIGH


1 CUS MAT VEH
WAITING AXLE 1 i
SET FILTER ?
