Dini Argeo 3590ET User Manual

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_16.03_EN_U
37
13.2.2 AUTOMATIC STATIC AXLE WEIGHING
13.2.2.1 CONFIGURATION
- Set parameter in the SETUP: F.ModE >> totAL >> AXLE W on “STATIC”.
- If before was setted the DYNAMIC axles weighing, the indicator ask to set the filter of this weighing mode, press
FN/ENTER to confirm.
- For a correct functioning one should correctly set the weighing parameters in the F.Mode >> total >> StA.CFG
menu of the Set-up environment or by a direct function 605, linked to a key. (See the TECHNICAL MANUAL):
1.”Min.Wei” (minimum weigh of the axle);
2.”Stab.tm” (Stability interval);
3.“tiME W” (interval between cycles);
4.”Skip B.” (Beginning axles to skip);
5.“Skip E.” (Ending axles to skip);
6.”Err.En” (Axle acquisition error enable);
7.”Tim.Out” (Axle acquisition time out).
13.2.2.2 WEIGHING PROCEDURE
- As soon as the indicator has completely turned on and enters in the weighing status, it waits for the first axle, the
indicator displays:
3590E
LED display LCD display
CPWE
[In which: XXXXXX is the current weight on the scale]
- Select, if requested, the customer / material / vehicle to be linked to the weigh.
- Drive and stop the first axle of the vehicle on the scale.
- Wait a few instants, the axle will be acquired when:
1) the weight is greater than the minimum weight of the set axle in << Min.Wei>> step.
2) the weight is stable.
- After the weight of the first axle is acquired, the indicator emits a sound and displays for an instant the following
message:
3590E
LED display LCD display

XXXXXX
CUS MAT VEH
WAITING AXLE 1
1 CUS MAT VEH
WAITING AXLE 1

AXLES: 1
TOT: YYYYY UM
SET FILTER ?
