3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_16.03_EN_U
13.2 SIMPLE AXLES WEIGHING
In this functioning mode, it is possible to get the weight of each axle and calculate their total weight, without any in/out
weighing function.
To enable this mode, one has to set the step F.ModE >> totAL >> In.out in the setup on “diSAbL”, (TECH.MAN.REF.).
13.2.1 MANUAL AXLE WEIGHING
13.2.1.1 CONFIGURATION
- Set parameter in the SETUP: F.ModE >> totAL >> AXLE W on “MANUAL”.
If before was setted the DYNAMIC axles weighing, the indicator ask to set the filter of this weighing mode, press
FN/ENTER to confirm.
13.2.1.2 WEIGHING PROCEDURE
- Select, if requested, the customer / material / vehicle to be linked to the weigh.
- Drive and stop the first axle of the vehicle on the scale then press F6 key to store the displayed weight.
- The indicator waits for stability and displays the following messages:
LCD display
- After the weight of the first axle is acquired, the indicator emits a sound and displays for an instant the following
message:
3590E
LED display LCD display
CPWE:
- Then the acquired weight blinks for a few seconds in the weight section (see section 5), and the indicator executes
the printout (if set in the corresponds print formats):
3590E
LED display LCD display
tot
WEIGH AXLE 2 ?
ENTER=YES C=NO
WEIGH AXLE 2?
ENTER=YES C=NO
WEIGH AXLE 2?
ENTER=YES C=NO
XXXXXX
WEIGH AXLE 2 ?
ENTER=YES C=NO
