Epson EH-TW6700W User Manual

Contents
3
Organization of the Guide and
Notations in the Guide
Using Each Guide ..................... 1
Notations Used in This Guide ........... 2
Safety Indications.......................2
General Information Indications .............2
About the Use of "This Product" or "This Projector" 2
Introduction
Projector Features .................... 6
Dynamic 3D Display ...................... 6
Project Images from Mobile Devices ..........6
Other Useful Functions .................... 6
Part Names and Functions ............. 7
Front/Top ............................. 7
Control panel .......................... 8
Remote Control ........................ 10
Rear ................................ 13
Base ................................ 14
Preparing
Installing ............................ 15
Projected Image and Position of Projector.....15
Installing in parallel with the screen ........ 15
Installing the projector horizontally by
adjusting the height of either side ......... 15
Various Setting Methods.................16
Placing on a table and projecting.........16
Suspending from the ceiling and projecting . . 16
Projection Distance and Lens Shift Maximum
Values ............................... 17
Connecting a Device ................. 20
Connecting Video Equipment ..............20
Connecting a Computer .................. 20
Connecting Smartphones or Tablets .........20
Connecting USB devices .................. 21
Connecting External Equipment............ 22
Connecting Bluetooth
®
devices..........22
Connecting external speakers (EH-
TW6700W/EH-TW6700/EH-TW6300 only) .... 24
Connecting WirelessHD devices (EH-
TW6700W only) ......................24
Connecting to the Trigger Out port (EH-
TW6800 only).......................25
Connecting to the LAN port (EH-TW6800
only) .............................. 25
Attaching the Wireless LAN unit ............26
Removing the Terminal Cover .............. 26
Preparing the Remote Control ........ 27
Installing the Remote Control Batteries.......27
Remote Control Operating Range ...........27
Operating range (left to right) ............ 27
Operating range (top to bottom) .......... 27
Basic Operations
Projecting Images ................... 28
Turning On the Projector.................28
If the target image is not projected . . . . . . . . 28
Using the Home Screen .................. 29
Turning Off ...........................30
Adjusting the Projected Image . . . . . . . . 31
Displaying the Test Pattern ................ 31
Adjusting the Focus ..................... 31
Adjusting the Projection Size (Adjust Zoom) . . . 31
Adjusting the Projector's Tilt ...............32
Adjusting the Position of the Image (Lens Shift) . 32
Correcting Keystone Distortion ............. 33
Correcting using the Keystone button......34
Correcting with Quick Corner............34
Adjusting the Volume .................... 35
Hiding the Image and Muting the Audio
Temporarily (A/V Mute) .................. 36
Adjusting the Image
Adjusting the Image ................. 37
Selecting the Projection Quality (Color Mode) . . 37
Switching the Screen Between Full and Zoom
(Aspect)............................. 38
Adjusting the Sharpness .................. 39
Adjusting Image Resolution (Image
Enhancement) ......................... 40
