3.3.6 MA Board (assembly)
1. Remove the Air Filter. (p.64)
2. Remove the Lamp. (p.64)
3. Remove the Rear Case. (p.66)
4. Remove the Front Case. (p.67)
5. Remove the Upper Case. (p.68)
6. Disconnect all the cables from the MA Board (assembly).
Figure 3-10.
Standard Operation Time 13 Min.
䎦䎱䎖䎜䎓䎕
䎦䎱䎖䎜䎓䎘
䎦䎱䎔䎖䎓䎔
䎦䎱䎜䎔䎓䎓
䎦䎱䎜䎖䎓䎓
䎦䎱䎜䎕䎓䎓
䎦䎱䎔䎓䎔
䎦䎱䎘䎖䎓䎔
䎦䎱䎘䎖䎓䎖
䎦䎱䎘䎖䎓䎓
䎦䎱䎘䎖䎓䎕
䎦䎱䎖䎜䎓䎚
䎦䎱䎖䎚䎓䎕
䎦䎱䎖䎜䎓䎔
䎦䎱䎖䎜䎓䎗
䎦䎱䎖䎜䎔䎔
䎦䎱䎖䎜䎓䎓
䎦䎱䎖䎜䎓䎛
䎦䎱䎖䎚䎓䎔
䎦䎱䎖䎜䎓䎙
䎦䎱䎖䎜䎓䎖
䎦䎱䎔䎖䎓䎕
䎦䎱䎗䎔䎓䎓
䎦䎱䎖䎚䎓䎓
䎦䎱䎔䎓䎕
䎦䎱䎖䎚䎓䎗
䎦䎱䎖䎜䎓䎜
Connector (Front side)
Connector (Back side)
Reference
CN No. Destination CN No. Destination
CN101/
CN102
Rx Wireless HD
(EH-TW9000W only)
CN3904/
CN3911
Auto Iris
CN1301/
CN5301/
CN5303
Lens Shutter CN3905 INT Fan (1)
CN1302 EIF Board CN3906 INT Fan (2)
CN3700 SW Board CN3907 EXT Fan
CN3701 BA Unit (SCI) CN3908 Lamp Fan
CN3702 RCF Board CN3909 PS Fan
CN3704 RCR Board CN4100 PS Unit
CN3900
LV Thermistor
(Optical Engine)
CN5300/
CN5302
Optical Engine
CN3901 TH1 Board CN9100 Optical Engine (L/V (R))
CN3902 TH2 Board CN9200 Optical Engine (L/V (G))
CN3903 TH3 Board CN9300 Optical Engine (L/V (B))
To Next Page
