EPSON LX-300+II/300+II RTP/1170II Revision D
LX-300+II RTP Parts List 106
7.3 Parts List
Ref No. Part Name Qty
100 HOUSING ASSY LOWER 1
101 HOUSING,UPPER;B 1
120 LOGO PLATE;RTP 1
121 SHEET,PANEL;RTP 1
129 C.B.B-TITE(W(13))SCREW,3X14,F/ZN-3C 2
200 BOARD ASSY.,MAIN 1
300 BOARD ASSY., POWER SUPPLY 1
320 HARNESS 1
401 HARNESS 1
402 SWITCH ASSY.,COVER OPEN 1
450 BOARD ASSY.,PANEL 1
501 FRAME ASSY.,LEFT 1
502 FRAME,RIGHT 1
503 MOTOR ASSY.,CR 1
504 EXTENSION SPRING,8.10 1
505 LEVER ASSY.,PLANET 1
506 SHAFT,CR,GUIDE 1
509 SPURGEAR,13.2 1
510 COMBINATIONGEAR,5.1,16.2 2
511 MOTOR ASSY.,PF 1
512 COVER,RD 1
513 RATCHET,RD 1
514 DETECTOR,LEAF,B2 1
515 GROUNDING WIRE,PLATEN 1
516 PULLEY ASSY.,DRIVEN 1
517 HARNESS,HP 1
520 PAPER GUIDE 1
521 DETECTOR,PE,REAR 1
522 HARNESS,PE,REAR 1
525 HOLDER,ROLLER,PF 2
526 ROLLER,PF,DRIVEN 2
527 ROLLER,PF,DRIVEN,REAR;C 2
528 COMPRESSION SPRING,13.72 2
529 SHAFT,RELEASE 1
530 PAPER GUIDE.,ASSY 1
531 E-RING,8,F/UC-3C 2
532 BUSHING,11 2
533 U-TYPE,11.2X0.13X16S/NA 1
534 PLAIN WASHER(B100166990) 1
535 PLATEN 1
536 CARRIAGE ASSY. 1
537 GROUNDING PLATE,HEAD 1
538 OIL PAD 1
539 LEVER,G,ADJUST 1
540 RIBBON MASK 1
541 TIMING BELT 1
542 BUSHING,PARALEL,ADJUST 2
543 CABLE,HEAD 1
559 DAMPER 4
560 FRAME,BASE 1
Ref No. Part Name Qty
