4.1.3 Service Checks After Repair
Before returning the printer back to the user, use the check list below to confirm the quality
of the repaired printer.
Table 4-4. Check List for Repaired Printer
Category Component Item to Check Check
Printer
Mechanism
Printhead
Is dot missing? OK NG
Are any wires broken? OK NG
Carriage
mechanism
Does carriage move smoothly?
CR movement is not noisy?
CR mechanism is not dirty?
CR mechanism is not oily?
OK NG
Is the CR motor assembly at the
correct temperature?
(Not overheating?)
OK NG
Paper feed
mechanism
Is paper advancing smoothly?
PF movement is not noisy?
PF mechanism is not dirty?
PF mechanism is not oily?
OK NG
Is the PF motor assembly at the correct
temperature?
(Not overheating?)
OK NG
Paper path
Are all the types of paper fed
smoothly?
OK NG
Does the tractor feed paper smoothly? OK NG
Is the paper path clear of obstructions? OK NG
Is the platen free of damage? OK NG
Ribbon mask Is the ribbon mask free of distortion? OK NG
Test printing Is the test printing successful? OK NG
Online
printing
Is the online printing successful? OK NG
Adjustment
Printhead
Is the platen gap adjusted correctly? OK NG
Is Bi-d adjustment value correct? OK NG
Initial setting
Have all user changeable settings been
reset to the default values?
OK NG
Version Up ROM version Latest ROM version ________ OK NG
Transportation
Ink ribbon Is ribbon removed? OK NG
Accessories
Are all the relevant parts included in
the shipment?
OK NG
Table 4-4. Check List for Repaired Printer (continued)
Category Component Item to Check Check
