Epson LX-300+II RTP - A.3 Parts List for LX-300+II and LX-1170 II

EPSON LX-300+II/300+II RTP/1170II Revision D
Appendix Parts List 117
A.3 Parts List
The following tables show parts name of the products. Refer to the exploded diagrams
for parts’ number.
 Parts List for LX-300+II
Table A-14. LX-300+II Parts List
Code Part Name
100 HOUSING ASSY LOWER
101 INSULATOR;A
102 INSULATOR;B
103 HOUSING,UPPER
104 SHIELDPLATE,LOWER
105 COVER ASSY.,PRINTER
106 KNOB;W
107 COVER ASSY.,PRINTER,REAR
109 SHEET GUIDE ASSY.
111 SHIELDPLATE,UPPER
115 COVER CONNECTOR,CS;W
116 HEXAGON NUT
117 GROUNDINGPLATE
118 GROUNDING PLATE,PANEL
119 EDGING;A
120 LOGO PLATE
123 FERRITE CORE,FPC-25-20
124 SHEET,PROTECT
125 CONNECTOR LOCK NUT
126 RIVET B-TITE (SCREW TYPE),3X12,F/ZN-3C
127 C.B.P-TITE SCREW,3X10,F/ZN-3C
128 C.B.S-TITE SCREW,3X4,F/ZN-3C
129 C.B.B-TITE(W(13)) SCREW,3X14,F/ZN-3C
130 C.B.(O) SCREW,4X8,F/ZG-3C
131 C.P.SCREW,3X4,F/ZN-3C
132 C.B.S-TITE SCREW,3X6,F/ZN-3C
180 GUIDE,STACKER
200 BOARD ASSY.,MAIN
300 BOARD ASSY.,POWER SUPPLY
320 FFC HARNESS
400 POWER CABLE
401 HARNESS
450 BOARD ASSY.,PANEL
451 SHEET,PANEL;D
500 PRINTER MECHANISM,M-3M10-100
501 FRAME ASSY.,LEFT
502 FRAME,RIGHT
503 MOTOR ASSY.,CR
504 EXTENSION SPRING,8.10
505 LEVER ASSY.,PLANET
506 SHAFT,CR,GUIDE
510 COMBINATIONGEAR,5.1,16.2
511 MOTOR ASSY.,PF
512 COVER,RD
513 RATCHET,RD
514 DETECTOR,LEAF,B2
Table A-14. LX-300+II Parts List
Code Part Name
