EPSON LX-300+II/300+II RTP/1170II Revision D
PRODUCT DESCRIPTION SPECIFICATIONS 13
Paper thickness lever:
The paper thickness lever must be set at the proper position as shown below.
1.2.3 Electrical Specification
1.2.4 Environmental Condition
Temperature: 5 to 35 °C (operating*
1
)
15 to 25
°C (operating*
1,
*
2
)
-30 to 60
°C (non-operating)
Humidity: 10 to 80% RH (operating*
1
)
30 to 60% RH (operating
*
1,
*
2
)
0 to 85% RH (non-operating
*
1
)
Resistance to shock: 1 G, within 1 ms (operating)
2 G, within 2 ms (non-operating
*
3
)
Resistance to vibration: 0.25 G, 10 to 55 Hz (operating)
0.50 G, 10 to 55 Hz (non-operating
*
3
)
*1: without condensation
*2: during printing on reclaimed paper, multi part paper, envelop, label or
roll paper.
*3: without shipment container
Table 1-5. Paper Thickness Lever
LX-300+II LX-1170II
Lever
position
Paper thickness
(inch)
Paper
thickness
(mm)
Paper thickness
(inch)
Paper
thickness
(mm)
Min. Max. Min. Max.
—1 — — — — — —
0 (0.0024) (0.0071)
over 0.06
up to 0.18
(0.0024) (0.0071)
over 0.06
up to 0.18
1 (0.0071) (0.0102)
over 0.18
up to 0.26
— — —
2 (0.0102) (0.0130)
over 0.26
up to 0.33
(0.0071) (0.0102)
over 0.18
up to 0.26
3 (0.0130) (0.0154)
over 0.33
up to 0.39
— — —
4 (0.0154) (0.0205)
over 0.39
up to 0.52
(0.0102) (0.0130)
over 0.26
up to 0.33
5 — — — (0.0130) (0.0154)
over 0.33
up to 0.39
6 — — — (0.0154) (0.0205)
over 0.39
up to 0.52
Table 1-6. Electrical Specification
120V version 230V version
Rated voltage AC 120 V AC 220 to 240 V
Input voltage range AC 99 to 132 V AC 198 to 264 V
Rated frequency range 50 to 60 Hz
Input frequency range 49.5 to 60.5 Hz
Rated current 0.6 A (max. 1.4 A) 0.3 A (max. 0.7 A)
Power consumption
Approx. 23 W (ISO/IEC 10561 Letter pattern)
Energy Star Compliant
Dielectric strength
AC 1000 Vrms. 1 min. or
AC 1200 Vrms. 1 sec.
(between AC line and chassis)
AC 1500 Vrms. 1 min.
(between AC line and chassis)
