EPSON LX-300+II/300+II RTP/1170II Revision D
Adjustment Adjustment Tool 86
5.1 Adjustment Tool
With the Adjustment Tool for SIDM, you can perform:
 Get Printer Information
 PG Adjustment
 Bi-d Adjustment
 Top Margin Adjustment
 Bottom Margin Adjustment
 Print Test
You can also use the following additional functions:
 Get Counter information
 EEPROM read/write
 Printer Initial Setting
 Firmware Update
 Get Fatal Error Code
5.1.1 System Requirement
 PC:
Windows-based PC equipped with a parallel and a USB interface
 OS:
Windows 2000 Professional Edition SP3
Windows XP Professional Edition SP1
Windows98 SE
5.1.2 Running the Program
Start up the Adjustment Tool for SIDM, and you will see the following screen.
Figure 5-1. Adjustment Tool for SIDM
Select a printer, port, and customer from the pull-down menu, and then you can select
either one of the two modes, Sequential adjustment mode and Particular
adjustment mode.
 Sequential adjustment mode:
This mode is specifically designed to assist repair/service technician; to perform
all necessary adjustment/settings in proper order. A wizard like menu helps you to
perform necessary adjustment in accordance with the type of repair you made.
 Particular adjustment mode:
This mode is useful if specific adjustment item or setting needs to be performed
individually. All available adjustment or setting item can be selected manually and
can be performed independently.
Click either one of the two buttons to start the mode you selected.
