EPSON LX-300+II/300+II RTP/1170II Revision D
Appendix EEPROM Address Map 114
A.2 EEPROM Address Map
This section provides the EEPROM address map.
NOTE: The data of two or more bytes are assigned as lower byte to lower
address and higher byte to higher address.
*1: The data are fixed by each printer hardware in the factory. The data
should not be changed afterwards.
NOTE: The data is fixed by each printer hardware in the factory. The data shold
not be changed afterwards.
Table A-13. EEPROM Address Map
Address Explanation Setting
QPIT
Settings
Factory
Settings
Area 0
00H-03H Reserved 00H 00H
04H-07H
Driving Line count for
ribbon change timing
0-0FFFFFFFFH(count)
See Remote spec TLcmd
00000000H 00000000H
08H-0BH Driving Hour
0-0FFFFFFFFH(minute)
See Remote spec TLcmd
00000000H 00000000H
0CH-0FH Driving Line count
0-0FFFFFFFFH(count)
See Remote spec TLcmd
00000000H 00000000H
10H Starting Year
0-99(the last two figures of Anno Domini)
See Remote spec SDcmd
00H 00H
11H Starting Month
1-12
See Remote spec SDcmd
00H 00H
12H Starting Data
1-31
See Remote spec SDcmd
00H 00H
13H Backup Flags
b0: In Tear Off state 0: No 1: Yes
b1 to b7: Reserved
00H 00H
14H-17H Reserved 0000H 0000H
Area1
18H,19H Page length for tractor
1 to 22x432 by 0.0588 mm (1/432 inch),
0000H : 279.4 mm (11 inches: same as default)
0000H 0000H
1AH,1BH Page length for CSF
1 to 22x432 by 0.0588 mm (1/432 inch),
0000H : 558.8 mm (22 inches: same as default)
0000H 0000H
1CH,1DH
Page length for rear
manual insertion
1 to 22x432 by 0.0588 mm (1/432 inch),
0000H : 558.8 mm (22 inches: same as default)
0000H 0000H
1EH,1FH
TOF adjustment value
for tractor
-144 to 432 (0.0 mm to 8.5 mm +25.4 mm
(1 inch), by 0.0588 mm (1/432 inch))
0000H
(8.5 mm)
0000H
(8.5 mm)
20H,21H
TOF adjustment value
for CSF
-144 to 432 (0.0 mm to 8.5 mm +25.4 mm
(1 inch), by 0.0588 mm (1/432 inch))
0000H
(8.5 mm)
0000H
(8.5 mm)
22H,23H
TOF adjustment value
for rear manual insertion
-144 to 432 (0.0 mm to 8.5 mm +25.4 mm
(1 inch), by 0.0588 mm (1/432 inch))
0000H
(8.5 mm)
0000H
(8.5 mm)
24H,25H
Bottom margin for
tractor
1 to 22x432 by 0.0588 mm (1/432 inch), 0000H :
279.4 mm (11inches: same as default)
0000H 0000H
26H,27H TOF Minimum value
-144 to -72, 0 : -72(4.2 mm)
In case that it is big than -72, a value considers as
-72
0000H 0000H
28H Font selection
0: Draft
1: Roman
2: Sans serif
00H
(Draft)
00H
(Draft)
29H Pitch selection
0: 10 cpi 3: 17 cpi
1: 12 cpi 4: 20 cpi
2: 15 cpi 5: Proportional
00H
(10 cpi)
00H
(10 cpi)
2AH Reserved 00H 00H
2BH,2CH Reserved 0000H 0000H
2DH Print direction setting
0:Bi-d.
1:Uni-d.
00H
(Bi-d.)
00H
(Bi-d.)
Table A-13. EEPROM Address Map (continued)
Address Explanation Setting
QPIT
Settings
Factory
Settings
To Next Page
