System Requirements
Consult the documentation for your software RIP.
Specifications Table
Printer Specifications
Printing method On-demand ink jet
Nozzle configuration 360 nozzles x 2 x 2 rows x 4 col-
ors (Black
*1
, Cyan, Magenta,
Yellow)
Resolution (maximum) 720×1440dpi
Control code ESC/P raster (undisclosed com-
mand)
Media Feed Method Friction feed
Built-in memory 512 MB for Main
128 MB for Network
Interface Hi-Speed USB-Compatible with
the USB 2.0 Specification.
100Base-TX/1000Base-T
*2
Rated voltage AC100-120V AC200-240V
Rated frequency 50/60 Hz
Rated current #1: 10 A
#2: 10 A
#1: 5 A
#2: 5 A
Power consumption
(total for numbers 1
and 2)
Printing: Approx. 760 W
Ready mode: Approx. 458 W
Sleep mode: Approx. 11 W
Power off: Approx. 1 W
Temperature Operating: 15 to 35˚C (15 to
25˚C recommended)
Storage (before unpacking):
-20 to 60˚C (within 120 hours at
60˚C, within a month at 40˚C)
Storage (before refilling with
ink):
-20 to 40˚C (within a month at
40˚C)
Printer Specifications
Humidity Operating: 20 to 80% (40 to 60%
recommended) (without con-
densation)
Storage (before and after un-
packing): 5 to 85% (without
condensation)
Operating Temperature/Humidity Range (area with diag-
onal lines: recommended)
Dimension Storage (minimum) dimen-
sions: 2620 (W) x 1013 (D) x 1314
(H) mm
Maximum dimensions: 2620
(W) x 1198 (D) x 1653 (H) mm
Weight
*3
Approx. 288 kg
*1High Density Black or Black
*2 Use a shielded twisted pair cable (category 5 or higher).
*3 Supplied media system installed; ink not included.
SC-F9200 Series User's Guide
Appendix
131
