It gives the status of each disk of each board. The different statuses are:
NOT PRESENT Disk is not found.
PRESENT Disk is present but Test unit ready function failed.
MAJOR ERROR A major error has been detected: Disk cannot be used.
READY Disk initialization succeeded.
NOT_READY Time out after attempting to start the disk.
VERIFY_ERROR An error occurred while verifying sectors on the disks.
The system can probably work for a while but should be
disconnected in operation.
LBA ERROR LBA size is not 512. System cannot work.
SYS ERROR All other possible errors.
Note:
The information regarding primary and grown defects is only available in
maintenance mode (start a hardware check in EVS maintenance menu).
XXX is the number of primary defects found on each disks. YYY is the
number of defects found on each disks.
Step 3: Board Capacity Display
After this table, the system displays the total capacity of all boards.
The message "Capacity of board #x: m.n GBytes or XXX blocs of YYY KBytes" is
displayed.
where:
x is the board number
m.n is the size of the board in base 1024*1024*1024 (Giga bytes)
XXX is the number of blocs available on the disks
YYY is the size of each bloc.
Possible Error Messages
• If a major error has been detected on a disk, it has been disconnected. In this
case, the system displays the message:
"!!! SCSI CONTROLLER #X DISCONNECTED!!!"
where X is the number of the controller. It is advised to replace this disk and to
rebuild its data if necessary.
In that case, start the CHECK program in EVS menu to rebuild.
