234 Troubleshooting
Entering Values
Using the operator panel, enter the values found in the color registration chart to make adjustments.
1 Press the (Menu) button.
2 Select Admin Menu, and then press the button.
3 Select Maintenance Mode, and then press the button.
4 Select Adjust ColorRegi, and then press the button.
5 Select Enter Number, and then press the button.
6 Ensure that Enter (LY,LM,LC) appears.
7 Press the or button to specify the values for LY, LM, and LC.
NOTE:
• To move the cursor to the next value, press the button.
8 Press the button.
9 Ensure that Enter (RY,RM,RC) appears.
10 Press the or button to specify the values for RY, RM, and RC.
NOTE:
• To move the cursor to the next value, press the button.
11 Press the button.
12 Ensure that Enter (PY,PM,PC) appears.
13 Press the or button to specify the values for PY, PM, and PC.
NOTE:
• To move the cursor to the next value, press the button.
14 Press the button.
NOTE:
• The registration values are always shown as 0 the next time you enter the menu.
15 Select ColorRegi Chart, and then press the button.
16 Ensure that Are You Sure? appears, and then press the button.
The color registration chart is printed with the new values.
If the straightest line is not at the value of 0, adjust the values again. Checking the charts before and after the
adjustments will help you to determine the values to enter.
After printing the color registration chart, do not turn off the printer until the printer motor has stopped running.
IMPORTANT:
• If the optional hard disk unit is not installed on your printer, note that the data in the memory are cleared when the printer is
turned off.
