32 Basic Operation
Main Components
This section provides an overview of your printer.
This section includes:
• "Front View" on page 32
• "Rear View" on page 33
• "Operator Panel" on page 34
Front View
IMPORTANT:
• To avoid irregular screen image or malfunctioning of your printer, avoid placing the printer in direct sunlight with the bypass
tray opened.
1 Belt Unit 7 Standard 550 Sheet Tray (Tray1)
2 Drum Cartridge 8 Bypass Tray
3 Waste Toner Box 9 Toner Cartridge
4 Side Cover 10 Front Cover
5 Power Switch 11 Operator Panel
6 Optional 550 Sheet Feeder (Tray2)
