Fujitsu AMILO User Manual

Connecting external d evices
Connecting an external monitor
An analogue monitor is connected to the analogue VG A monitor port, a digital monitor to
the DVI-I monitor port. Monitor output is limited to a maximum of two monitors at any one
time (see "
Key combinations", Page 19, section "Toggle outp ut monitor").
MonitorVGA connection socketScreenportMonitorport
Digital DVI-I monitor port
Analogue VG A monitor p ort
► Switch off the notebook an
d the external monitor.
► Connect the data cable of the external monitor to the monitor port of the notebook.
► First switch on the externa
l monitor and then the notebook.
Using the
Fn
+
F10
key combinati
on, you can toggle back and forth between
the externa l monitor and
the notebook’s LCD screen.
You can display the same p
icture on the external monitor and the
notebook LCD screen simu
ltaneously.
56 A26391-K90-Z200-1-7619, edition 1
