Connecting extern al de v ices
Connecting an external SATA hard disk (eSATA)
An extern al SATA hard disk can be connected at the eSATA/USB combination port. This allows you to
expand the internal hard disk capacity as you wish. You should obtain a hard disk with a robust casing.
The cable is not included in the delivery scope. It can be obtained through your
retailer. The length of the eSATA cable m u st not exceed 2 metres. Simple SATA
cables are designed for installation in devices and canno t be used due to the
differences in pin alloca tion. Please consult a specialist retailer for advice.
The data transfer rate is up to 2,400 Mbit/s.
eSATA
► Connect the data cable to the external
device.
► Connect the data cable to the eSATA/USB
combination port of the computer.
Device driver
The eSATA hard disk is a utomatically recognised by your operating system and installed.
You will find more in
formation in the documentation for the external SATA
hard disk and the op
erating system.
Safe removal of eSA
TA and USB devices
In order to protec
t your data, always follow the correct procedure
for removing the d
evice outlined below.
► Left-click on the icon.
► Select the device
you want to stop and remove.
► Press the Enter key.
Wait f or the dialog
ue box which tells y ou that it is now safe to remove the device.
A26391-K90-Z200-1-7619, edition 1 59
