Ports and controls
Ports and controls
This chapter presents the individual hardware co mponents of your device. It gives an
overview of the indicators and connections of the device. Please familiarize yourself
with these items before you start to work with the device.
Front
4
5
6
3
2
1
1
9
10
8
8
1 = Speaker
2 = Power-on indicator
3 = Touch screen
4 = $PELHQWOLJKWVHQVRU
5 = )URQWZHEFDP
6 = :HEFDPVWDWXV/('EOXH
7 = Battery charging indicator
8 = Mechanical
attachment for the keyboard
cover or cr
adle
9 = Docking port
10 = Center ali
gnment point
10 Fujitsu
