GE Optima XR646 User Manual

Chapter 12: Image Management
5495975-1EN Rev.9 12-10
© 2013-2017 General Electric Company. All rights reserved.
Note: Pressing the Eject button on the workstation PC does not open the disk tray. When working on the
Image Management screen, always use the Eject option from the [CD1] drop-down list
(Figure 12-7).
Figure 12-7 CD 1 button drop down list
2. Insert a blank disk into the tray.
3. Click Source [CD1] to close the disk tray.
4. Select the exams to copy.
5. Click the Destination [CD1].
 The CD Write screen appears.
 [DESELECT ALL] unchecks all exams on the list.
 [STORE OPTIMALLY] determines which exams to copy to best utilize the space on the disk. It will
automatically uncheck exams that cannot fit on the disk.
 [WRITE] begins the copying process.
 [CANCEL] closes the screen and returns you to the Image Management screen.
6. Confirm the exams to be copied. Uncheck any exams that you do not want saved to the disk.
7. Click [WRITE].
 The disk begins copying. The light on the front of the computer flashes yellow as the data is being
written.
 To see the status of the exams being copied, click [TRANSFER LOG] at the bottom of the Image Man-
agement screen.
 The Transfer Log screen appears.
 Click [CLOSE] to close the screen and return to the Image Management screen.
 When complete, the disk tray will open and close.
8. After the system finishes the disk, open the exams on the disk to ensure that the disk has the data
written to it. Refer to Load Images from a CD or DVD
(p. 12-5) for more information.
