8-3-6-5 Upper eTower Front Cover Installation Procedure
1.) Install the Printer Insert Cover or Printer Frame Cover (depending on system configuration) on the
Upper eTower Cover and secure with two Phillips screws.
2.) Install the Upper eTower Cover on the scanner.
3.) Refit the following covers: Lower Front eTower cover, Right Side eTower Cover and the Left Side
eTower Cover and RS Probe Cover.
4.) Install all accessories.
• Right Side eTower Cover Installation Procedure
• Left Side eTower Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• RS Probe Cover Installation Procedure
• Accessories - Replacement Procedures
Perform the checks listed in Upper eTower Front Cover Replacement Procedure on page 8-216
