D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
Chapter 3 - System Setup 3-23
PRELIMINARY
The current drain will vary depending on the mains voltage.
• At 240 VAC the current may be up to 2.08 A.
• At 100 VAC the current may be up to 5 A.
3-5-4 Connections on the I/O Rear Panel
NOTE: Accessory equipment connected to the analog and digital interfaces must be certified according to the
respective IEC standards (e.g. IEC60950 for data processing equipment and IEC60601-1 for medical
equipment). Furthermore, all complete configurations shall comply with the valid version of the system
standard IEC60601-1-1. Everybody who connects additional equipment to the signal input part or signal
output part of Venue™ , configures a medical system, and is therefore responsible that the Ultrasound
system complies with the requirements of the valid version of IEC60601-1-1. If in doubt, consult the
technical service department or your local representative for GE.
3-5-4-1 Connect Ethernet
Connect the network cable to the Ethernet connector on the External I/O.
The connector is located on the rear side of Venue™ .
3-5-4-2 Connect USB Flash Card
Insert the USB Flash Card in one of the USB ports on the Venue™ .
Table 3-14 Electrical Specifications for all Venue™ Models
Voltage 100-240 VAC ±10%
Power Consumption 500 VA
Frequency 50-60 Hz
To Next Page
