Chapter 8 - Replacement Procedures 8-35
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-4-4-5 SSD Module Installation Procedure
1) Insert the SSD module into its slot and tighten the captive screw.
2) Close the FE door and close the two fastening latches on the left side of the Front End door
assembly.
3.) Tighten the captive screw.
4.) Refit the following covers: Lower Front eTower, left side eTower, right side eTower and RS Probe
Cover.
Ins
5.) Install all accessories.
6.) Turn ON power to the system.
• Left Side eTower Cover Installation Procedure
• Right Side eTower Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• RS Probe Cover Removal Procedure
• Accessories - Replacement Procedures
Perform the checks listed in SSD Module Replacement Procedure on page 8-217
