8-44 Section 8-4 - System Modules- Replacement Procedures
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-4-7-5 Battery Module Installation Procedure
1.) Return the batteries into the scanner in the direction shown by the arrow on the label. See the figure
above.
2.) Tighten the two mounting screws for each battery.
3) Refit the following covers: Lower Front eTower cover, Right Side eTower Cover, Left Side eTower
Cover, MPB Door Cover and RS Probe Cover.
4.) Install all accessories.
• MPB Door Cover Installation Procedure
• Right Side eTower Cover Installation Procedure
• Left Side eTower Cover Installation Procedure
• Lower Front eTower Cover Installation Procedure
• RS Probe Cover Installation Procedure
• Accessories - Replacement Procedures
Perform the checks listed in Battery Module Replacement Procedure on page 8-217
