XMTC User’s Manual 93
Appendix E. CE Mark Compliance
Appendix E. CE Mark Compliance
E.1 CE Mark Requirements
Note: If you follow the instructions in this section, your unit will comply with the EMC Directive.
WARNING! CE Mark compliance is required for all units installed in EU countries.
WARNING! To meet CE Mark requirements, you must shield and ground all electrical cables as
described in this section (see Table 5 below).
Table 5: Wiring Requirements for CE Mark Compliance
Connection Termination Modification
Power/Analog Output 1. When connecting the line power/analog output cable, select the cable entry closest to the
terminal blocks.
2. Use shielded cable* to connect the line power and the 4-20mA analog output device to the
XMTC. It is recommended to use GE P/N X4(*) or equivalent for all weatherproof
installation, and GE P/N Z4(*) or equivalent for all explosion/flameproof installation.
3. Terminate the shield to the cable gland. It is recommended to use GE P/N 419-215 or
equivalent for all weatherproof installation and GE P/N 419-217 or equivalent for all
explosion/flameproof installation.
RS232 Output 1. Use shielded cable* to interconnect the XMTC enclosure with any external I/O devices. It
is recommended to use GE P/N 704-668-12 or equivalent for all weatherproof installation
and GE P/N 704-1262-12 or equivalent for all explosion/flameproof installation.
2. Terminate the shield to the cable gland. It is recommended to use GE P/N 419-215 or
equivalent for all weatherproof installation and GE P/N 419-217 or equivalent for all
explosion/flameproof installation.
*Wires enclosed in a properly-grounded metal conduit do not require additional shielding.
WARNING! Cable entries of an approved flameproof design are required. These must be
installed according to the manufacturer’s instructions. The choice of cable entry device may limit
the overall installation category achieved.
WARNING! It is the responsibility of the user to ensure that all cable entry devices and covers
are properly installed and secure prior to applying power to the XMTC.
