Appendix D. The Enhanced Advanced Option
86 XMTC User’s Manual
D.1 Entering the Enhanced Advanced Option (cont.)
Along with Fast Response, Language, and Meter ID discussed in Chapter 3, the enhanced Advanced Menu offers four
additional commands:
• Heater - sets a specified operating temperature for the XMTC cell.
• Balance Bridge - compensates the XMTC cell for nonlinearity in the bridge (for factory use only).
• Factory Commands - allows users to upload or download modified settings or to reset the values to the
factory defaults.
• Temperature Comp. - allows entry of temperature calibration values (for factory use only).
Click on the desired option to open it, or click on Next Item/Enter to open the menu listed on the status line above the
options. (Click Previous Item or Exit Page to close the window without entering any commands.)
D.2 Heater
The parameters in the Heater command affect the operation of the Heater controls. The window for the Heater
command is similar to Figure 75 below.
Figure 75: Temperature Comp. Window
The first command, Setpoint Degrees C, asks you to enter the Heater Setpoint (the temperature at which the cell is
maintained). Enter the desired temperature (in degrees C) and press Next Item/Enter to confirm the entry. (For any
command, click Previous Item to return to the previous parameter, or Exit Page to close the window without changing
any values.)
