Chapter 2. Installation
18 XMTC User’s Manual
2.5.2 TMO2D Display
The GE TMO2D Display provides a two-line x 24 character back-lit LCD. It also features display and option
programming, recorder outputs, alarm relays, and optional relays for driving sample system solenoids for automatic
zero and span calibration of the XMTC. See Figure 72 on page 83 for an interconnection diagram for the XMTC and
the TMO2D, and refer to the TMO2D User’s Manual (910-084) for details on its operation.
2.5.3 XDP Display
The XDP Explosion-proof Display Package provides an integral, voltage-stabilized 24 VDC power supply, a 3-digit
display with adjustable 4-20 mA input range, two SPDT alarm relays rated for 1 A/250 VAC, and a 4-20 mA output
that is isolated from the input and adjustable to a second independent range if required. The XDP is supplied in a
weatherproof and explosion-proof enclosure that is rated for EEx d IIC T6 and IP66. See Figure 72 on page 83 for
interconnection diagrams for the XMTC and the MIS-1, MIS-2 and MMS-3 analyzers, and refer to the XDP User’s
Manual (910-204) for details on its operation.
2.5.4 Moisture Series Analyzers
The GE Moisture Image Series 1 (MIS-1) and Moisture Monitor Series 3 (MMS-3) analyzers accept inputs from a
variety of sensors (including the XMTC) and offer new graphical and digital user interfaces, improved performance,
and low range calibration. See Figure 72 on page 83 for interconnection diagrams for the XMTC and the MIS-1 and
MMS-3 analyzers, and refer to the appropriate User’s Manual for details on operating the MIS-1 (910-108) or MMS-3
(910-110) analyzer.
