Chapter 3. Operation and Programming
36 XMTC User’s Manual
3.9.2 Edit Point X
To edit the value for any particular point, click on that point in the Factory Cal window. A window similar to Figure 41
below opens.
Figure 41: Point Editing Window
Enter the gas percentage in the text box, and click on Next Item/Enter to confirm the entry. (Click Previous Item or Exit
Page to close the window without changing the value.) Then, enter the next value, as shown in Figure 42 below.
Figure 42: Additional Values for Point 1
Enter the x01 and x10 Gas mV values, and click on Next Item/Enter after each entry. After you have completed entering
values, you are returned to the Factory Cal window.
